Description

Product Description

Perfectly straight cuts. The micro-adjustable, precise and stable longitudinal stop provides decisive advantages: Corrections even smaller than 0.004″ (1/10mm) may also be made after coarse adjustment the use of an adjusting screw. The height is adjustable and 45 degrees tiltable saw blade makes it conceivable to cut double mitres when used along side the angle stop. Low-noise drive the use of DC special motor with compound belt driver. Ball-bearinged saw blade shaft. Tungsten tipped saw blade diameter 80mm (3 9/64″) x 1.6mm (1/16″) x 10mm (13/32″) (36 T). Additional work piece pusher and non-slotted ABS sawing gap cover for tight tolerances between saw blade and table. Technical data: 110 – 120V AC. 60Hz. 7,000rpm. Mitre infinitely adjustable as much as 45 degrees. Table size 12″ x 12″ (300 x 300mm). Cutting depth 0.04 – 5/6″ (1 – 22mm). Saw blades between 2 – 3 11/32″ (50 – 85mm) can be utilized (with 13/32″ (10mm) centre hole). Weight approx. 12 lb (6kg).

From the Manufacturer

Proxxon 37070 3-11/32-Inch Table Saw engineered in Germany for perfectly straight cuts. The ideal machine for model building, picture framing, doll houses, birdhouses and other intricate projects such as fine mechanics, mold construction, toy manufacture, architects, model carpenters and fitters. The Proxxon 37070 has many features for the precision craftsman. Adjustable setting stop/fence has setting screw for five adjustments of longitudinal stop by 0.004-Inches 1/10 millimeter for very precise cuts. Blade angle is also adjusted from 0 to 45 degrees for miter cuts. Blade can also be raised or lowered to accommodate the optimum height for quite a lot of materials being cut. Double miter cuts are conceivable when height adjustment and 45 degree tiltable saw blade are used along side angle stop. Low noise drive the use of DC special motor with compound belt driver. Ball bearing saw blade shaft. Tungsten carbide tipped saw blade comes with saw. Size 3-9/64-Inch diameter x 1/16-Inch wide kerf, 24 tooth blade is good for general purpose cuts with wood, non-ferrous metals, plastics, Plexiglass, fiberglass foam and other materials. Stable and sturdy construction because load bearing parts and plane milled table are made of die cast aluminum. Extendable table extension with integrated auxiliary stop provides for very accurate cuts of larger materials. Meter gauge comes with angle stop rail of aluminum and an adjustable limit stop for manufacturing parts of equal length and the same angle. Adjustable meter runs in milled slot in table top for precision accuracy. Vacuum cleaner adapter permits clean working. Technical Data: 110-120 Volt AC 60Hz, 7000 RPM. Miter infinitely adjusts as much as 45 degrees. Table size is 12 x 12-Inches or 300 x 300 millimeters. Cutting depth 0.04 – 5/16-Inch (1 – 22 millimeter). Saw blades arbor is 13/32-Inch or 10 millimeter.

The ideal machine for model building, picture-framing, dollhouses, birdhouses and other intricate projects
For fine mechanics, model building, mould construction, toy manufacture, architects, model carpenters and fitters
For cutting wood, non-ferrous metals, plastics, Plexiglas, fiber-glass reinforced sheets, foam and plenty of other materials
Stable construction because load bearing parts and plane-milled table are made of die-cast aluminium
Scope of delivery: 1x PROXXON Table Saw FET including tungsten tipped saw blade, vacuum cleaner adapter. Part number: 37070
